2835SMD Square 6W AC90V - 265V Surface Mounted LED Panel Light
Ceiling Light
Quick Details
---Power:6W
---Input Voltage:AC90-265V
---Lamp Diameter:120 x 120mm
---Luminous Flux:90 ~ 100 lm/W
---CRI > 80Ra
---Color:Warm White /Nature White / Cold White
---Warranty:Two years
Specification
(1) High brightness: > 90 LM /W .
(2) Energy saving up to 80% .
(3) Nice lighting distribution: > 90 %
(4) High color rendering index: Ra> 80,Ra>85 optional.
(5) Easy and fast installation,no need to open hole.
(6) Low optical decay.
(7) Instant starting time of led panel light: < 1.2 s, and no
noise as it starts.
(8) Environment friendly: No mercury, no harm to human healthy and
the earth.
Technical Datas
| Model No. | AL-SM2835S-6W |
| Input Voltage | AC90-265V |
| Power | 6W |
| Lumen | 600lm |
| Size | 120 x 120mm |
| Color Temperature | 3000k / 4000k / 6500K |
| LED Chip | Taiwan Epistar,2835SMD |
| CRI | Ra > 80 |
| LED Qty | 30pcs |
| PF | >0.92 |
| Lifetime | 4000H |
| Beam Angle | 180degree |
| Housing Color | White |
| Housing Material | Die-casting Aluminum |
| Operation Temperature | -200C ~400C |
| Dimmable | NO |
| IP Grade | IP20 |
| Installation | Surface Mounted |
| Single Package Dimension | |
| Single Package Weight | |
| Shape | Square |
| Certification | CE,RoHS |
| Warranty | 2 years |
Material & Structure
| LED Chip | Imported 2835 high brightness LED,high CRI,long lifetime. |
| Radiator | Integrative die-casting aluminum,with streak on the housing,good
heat dissipation. |
| Diffuser Plate | High light transmission,light is uniform and soft,can protect your
eyes. |
| Light Guide Plate | Professional optical LGP,light is uniform,and no dark area. |
| Reflective Sheeting | Reflective rate > 95%. |
| Base Board | Aviation aluminum,good heat dissipation,no deformation. |
| Connector | Male and female plug,easy and safe installation |
| Cable Wire | Red copper ,with PC insulating layer,high temperature
resistant,safe for using, |
| Driver | Intelligent constant current isolated driver,safe and reliable. |
| Installation Bracket | Die-casting aluminum |
| Screw | Aluminum |
Competitive Advantage
1--High bright 2835SMD LED chip,high lumen,high CRI,long lifespan.
2--Superior aviation aluminum under anodic oxidation
treatment,beautiful surface and durable lamp body.
3--Quality PMMA PLG and diffuser,uniform & soft lighting
effect,protect your eyes.
4--Surface mounted,easy and convient to install and replace.
5--10 years manufacturing & exporting experience,factory has strong
team to help you finish your
project according to your requirements.
Warning Note:
1) Please make sure that power is off during the whole installation
procedure.
2) Please make sure the connecting voltage is AC90-265V,and don't
exceed the working voltage range.
3) This lamp has to be installed for indoor,please don't light for
outdoor lighting.
Shipping
Tag:
Surface Mounted LED Panel Light,Surface Mounted LED
Downlight,Surface Mounted LED Ceiling Light
Raw Materials
6W Surface Mounted LED Panel Light Photo Show
